Chemical Compositions :
| Chemical Element | % |
|---|---|
| Cu | 62.00 - 64.00 |
| Al | 0.0 - 0.05 |
| Fe | 0.0 - 0.10 |
| Pb | 0.0 - 0.10 |
| Ni | 0.0 - 0.30 |
| Others (total) | 0.0 - 0.10 |
| Sn | 0.0 - 0.10 |
| Zn | Balance |
Physical Properties :
| Property | Value |
|---|---|
| Density | 8.44 kg/m3 |
| Melting Point | 916°C |
| Modulus of Elasticity | 103.4 GPa |
| Thermal Conductivity | 116 W/m.K |
| Thermal Expansion | 20.5x10-6 /°C |
Mechanical Properties :
| Property | Sheet | Tube |
|---|---|---|
| Tensile Strength | 300 - 550 MPa | 440 Min MPa |
| Proof Stress | 110 - 500 MPa | 320 Min MPa |
| Elongation A50 mm | 38 - 3% | 10 Min % |
| Hardness Vickers | 55 - 180 HV | 115 Min HV |
| Hardness Brinell | - | 110 Min HB |
